MA-X™ M63
MA-X expands façade possibilities while maintaining strong structural performance, including wind loads exceeding 100 PSF with the optional cleat (patent pending). A drained and back-ventilated rainscreen, it delivers long-term reliability, while Fluoropolymer-based finishes ensure lasting durability supported by eco-friendly manufacturing practices. The .063” material thickness provides a more economical option compared to M80, while maintaining system performance.
Rigorously tested for structural integrity, rainscreen, and wind performance, the M80 system seamlessly converges form, function, and value.
Patent-pending panel configuration and cleat design.
HVHZ, Impact Testing, and FL Product approved on select configurations.
Product Highlights
- Large format panels
-
Limitless color options
-
Durable finish
- Eco-friendly practices
Downloads
Technical Information
- System Depth
- Material
- Material Thickness
- Panel Joints
- Finish
- Weight
- Finish Warranty
- Maximum Panel Sizes
Standard Flat Depth: 1 1/2"
Maximum Flat Depth: Up to 4" in 1/8" increments
Aluminum
0.063"
1/2" Horizontal, 5/8" Standard
*Please consult technical advisor for custom panel joints*
Post Paint: 70% PVDF
Fluoropolymer
Anodized: Clear or Colored
<2 pounds per square foot
Anodized: 5 years standard (10 years available)
4' W x 12' H for Vertical in select applications
