NEW PRODUCT
MA-X™ M80
Large-format aluminum panel system that delivers bigger panel sizes, high wind-load performance, and faster installation, giving architects more design flexibility and installers a lower-cost alternative. Crafted from robust .080” aluminum, MA-X is for architects who want larger panels with increased design flexibility. For installers, larger panels mean fewer panels to install.
Rigorously tested for structural integrity, rainscreen, and wind performance, the M80 system seamlessly converges form, function, and value.
Patent-pending panel configuration and cleat design.
HVHZ, Impact Testing, and FL Product approved on select configurations.
Product Highlights
- Large format panels
-
Limitless color options
-
Durable finish
- Eco-friendly practices
Downloads
Technical Information
- System Depth
- Material
- Material Thickness
- Panel Joints
- Finish
- Weight
- Finish Warranty
- Maximum Panel Sizes
Standard Flat Depth: 1 1/2"
Maximum Flat Depth: Up to 4" in 1/8" increments
Aluminum
0.080"
1/2" Horizontal
5/8" Vertical
**Please consult technical advisor for custom panel joints.
Post Paint: 70% PVDF
Fluoropolymer
Anodized: Clear or Colored
<2 pounds per square foot
Paint: Up to 20 years
Anodized: 5 years standard (10 years available)
Anodized: 5 years standard (10 years available)
12' W x 4' H for Horizontal
4' W x 12' H for Vertical in select applications
